| Perfect waterjet trimming (Trimming free 100%) |
| highly energy efficient design all axis driven by servo motors |
| smooth working |
| minimum periodically maintenance |
| Electrical control cabinet Containing the switch gears and Total of five servo drives three @ 2kw and two @400 w |
| M/C Model | ECOFA-9570-60T-SERVO-SS |
|---|---|
| Table Size | 950*700 MM |
| Output /Day | UP TO 425 KG As per product |
| machine dimension | (L x W x H) 4 x 1.9 x 4 meter |
| maximum product height | 40 MM |
| No. of drying station | 1 |
| pressing force | 60 ton |
| cycle time | 33-40 second as per product |
| linear moment | servo motor |
| forming platen moment | servo motor |
| pressing | servo motor |
| counting & stacking | servo motor |
| Parameters | UOM | ECOFA-12085 |
|---|---|---|
| Pulp Molding Capacity | kg/Day | 750 |
| Mold Platten Length | mm | 1200 |
| Mold Platten Depth | mm | 850 |
| Mold Platten Area | mm² | 1020000 |
| Method of Forming | dip forming | |
| Method of Hot Pressing & Drying | Hot Pressing done by Hydropneumatic Cylinder | |
| Hydraulic Pressing Force | Tons | 60 |
| Min Shut Height | mm | 250 |
| Product Depth | mm | <100 |
| Product Thickness | mm | <3 |
| Compressed Dry Air Requirement | Bar | 6.5 |
| Compressed Dry Air Requirement | CFM | 60 |
| Vacuum Requirements | m³/min | 14 |
| Vacuum Requirements | mm Hg | 500 -ve |
| Heating Method -1 | Oil Heating | |
| Heating Load-1 | 15 | |
| Heating Method -2 | Electric Heating | |
| Heating Load-2 | KW | 150 |
| Heating Requirement | Kcal/Hr | 140000 |
| Mold Oil Inlet Temperature | ºC | 240±10 |
| Control System | Control cabinet consist of PLC, HMI & PID | |
| Machine Size-Lx WxH | mm | |
| Machine weight | kg | |
| Material of construction | MS with SS-304 clading |
| Parameters | UOM | ECOFA-1311 |
|---|---|---|
| Pulp Molding Capacity | kg/Day | 850 |
| Mold Platten Length | mm | 1250 |
| Mold Platten Depth | mm | 1050 |
| Mold Platten Area | mm² | 1312500 |
| Method of Forming | dip forming | |
| Method of Hot Pressing & Drying | Hot Pressing done by Hydropneumatic Cylinder | |
| Hydraulic Pressing Force | Tons | 60 |
| Min Shut Height | mm | 250 |
| Product Depth | mm | <100 |
| Product Thickness | mm | <3 |
| Compressed Dry Air Requirement | Bar | 6.5 |
| Compressed Dry Air Requirement | CFM | 60 |
| Vacuum Requirements | m³/min | 14 |
| Vacuum Requirements | mm Hg | 500 -ve |
| Heating Method -1 | Oil Heating | |
| Heating Load-1 | 15 | |
| Heating Method -2 | Electric Heating | |
| Heating Load-2 | KW | 150 |
| Heating Requirement | Kcal/Hr | 140000 |
| Mold Oil Inlet Temperature | ºC | 240±10 |
| Control System | Control cabinet consist of PLC, HMI & PID | |
| Machine Size-Lx WxH | mm | |
| Machine weight | kg | |
| Material of construction | MS with SS-304 clading |
